48V 20Ah LiFePo4 Battery Pack Designed for AGV

Advantages:

---

Firstly-EXCELLENT POWER:

1. BMS that meets the safety peak discharge can be designed according to specific needs

2. Built-in battery safety management system,immediately respond to cut off the power when

   an abnormality occurs

3. The raw materials meet the Rohs 2.0 Standard, which is safe and environmentally friendly

Secondly-EXCELLENT SAFETY PERFORMANCE

1.  Built-in balance,can automatically balance the voltage when charging

2.  Built-in multiple indepedent temperature sensors, through BMS control to protect the safe

       discharge   protection, short circuit protection

Thirdly-DIVERSIFIED STRUCTURAL DESIGN

1.  The battery shape can be designed according to different models

2.  Support deep customization based on functions

3.  Safe and reliable structural and thermal runaway tests

Technical Details

---

Cell	Lithium-Iron phosphate prismatic cell
Voltage	48V
Energy	4.8kWh
Rated Power	0.96kW
Maximum Power	1.25kW(<10s)
Cooling Way	Natural Cooling
Weight	12.5KG
Charge Mode	Slow Charging 50A (2~3Hrs)
Charge Type	DC Charger
Waterproofing Standard	IP66
